6000mAh battery

Multiple alarms

BDS/GPS/WIFI/GLONAS

Voice monitoring & recording

Light sensing anti-dismantling alarm

GSM Frequency

GSM850/900/1800/1900Mhz

GPRS

Class 12, TCP/IP

RAM

32MB+32MB

Max frequency error

±0.1ppm

Antenna

GPS/BDS, GSM, WIFI

LED indicator

GPS yellow, GSM green, Wifi blue

GPS Specification

Frequency

BDS: 1561.098MHZ, GPS L1: 1575.42MHZ

GPS chip set

MTK

GPS channel

32

Location accuracy

<3 meters

Tracking sensitivity

-166dBm

Acquisition sensitivity

-148dBm

TTFF (open sky)

Avg. hot start≤1sec
Avg. cold start≤35sec

Functional Specification

Battery

3V 6000mAh lithium battery

Wire

Wireless connection

Operating temperature

-20℃～ 70℃

Device dimension

83.5(L)X56.5(W)X28.5(H) (mm)

Device weight

181g
