Product Display
3D模型下载温馨提示：模型文件格式为：.STEP，
请安装相关软件(三维设计软件Pro/E、UG、CATIA、Solidworks等等)后才能正常预览。
Product Specifications


Functions

Multiple alarms


Free installation

Voice monitoring & Recording

History playback

Beidou/GPS+GPRS positioning



Spec

GSM Specification

GSM Frequency

GSM850/900/1800/1900Mhz

GPRS

Class 12, TCP/IP

LED

LED light

GPS chip set

MTK2503DL

Standby current

40mA (12V DC), 20mA (24V DC)

Working votage

9-24V DC

GPS Specification

Speed accuracy

0.1m/s

Max speed

180m/s

Location accuracy

<5 meters

Tracking sensitivity

-163dBm

Max frequency error

±0.1ppm

Acceleration of gravity

≤4g

TTFF (open sky)

Avg. hot start≤2sec
Avg. cold start≤32sec

Functional Specification

Operating temperature

-20℃～ 70℃

Device dimension

47.5(L)X32.5(W)X28.5(H) (mm)

Device weight

32g
