Multiple alarms

9-90V voltage range

FOTA

GEO fence

GSM frequency

850/900/1800/1900 Mhz

GPRS

Class 12, TCP/IP

Memory

32Mb+32Mb

LED indicator

GPS blue, LTE green

Max output

GSM850/GSM900:33±3dBm
GSM1800/GSM1900:30±3Bm

Max frequency error

±0.1ppm

GPS Specification

GPS chipset

MTK high sensitivity chip

Frequency

GPS L 1,1575.42MHZ

GPS channel

32

Location accuracy

<3 meters

Tracking sensitivity

-162dBm

Acquisition sensitivity

-148dBm

TTFF (open sky)

Avg. hot start≤1sec
Avg. cold start≤35sec

Functional Specification

Working voltage/current

9-90VDC/54mA(12V)

Stand-by current

<5mA

Operating temperature

-20℃～ 70℃

Device dimension

66.0(L)*27.0(W)*13.7(H)mm

Device weight

23g
